MODEL
|
NG35 PRO4K
|
NG35 PRO5K
|
NG35 PRO6K
|
NG35 PRO8K
|
NG35 PRO10K
|
NG35 PRO12K
|
|
Nominal Battery System Voltage
|
24V
|
48V
|
24V
|
48V
|
48V
|
48VDC
|
48VDC
|
48VDC
|
|
INVERTER
OUTPUT
|
Rated power
|
4KW
|
5KW
|
6KW
|
8.0KW
|
10.0KW
|
12.0KW
|
|
Surge rating
|
12000VA
|
15000VA
|
18000VA
|
24000VA
|
30000VA
|
36000VA
|
|
Capable of starting electric motor
|
2HP
|
2HP
|
3HP
|
4HP
|
5HP
|
6HP
|
|
Waveform
|
Pure sine wave \ same as input (bypass mode)
|
|
Nominal output voltage RMS
|
220V \ 230V \ 240VAC (±10%RMS)
|
| Output frequency |
50Hz \ 60Hz+0.3Hz
|
|
Inverter effciency(peak)
|
>85%
|
>88%
|
|
Line mode efficiency
|
>95%
|
|
Power factor
|
1.0
|
|
Typical transfer time
|
20ms(max)
|
|
AC INPUT
|
Voltage
|
230VAC
|
|
Selectable voltage range
|
90-280 VAC (APL)
|
|
Frequency range
|
50Hz \ 60Hz
|
|
BATTERY
|
Low battery voltage cutoff
|
20-24VDC for 24VDC mode (40-48VDC for 48VDC mode)
|
|
Low battery voltage recover
|
21-25VDC for 24VDC mode (42-50VDC for 48VDC mode)
|
|
High battery voltage cutoff
|
30VDC for 24VDC mode (60VDC for 48VDC mode)
|
|
High battery voltage recover
|
28.5VDC for 24VDC mode (57VDC for 48VDC mode)
|
|
Idle consumption-search mode
|
<30W when power saver on
|
<80W when power saver on |
|
AC CHARGER
|
Output voltage
|
Depends on battery type
|
|
Charger AC input breaker rating
|
40A
|
40A
|
50A
|
80A
|
80A
|
80A
|
|
Overcharge protection S.D.
|
31.4VDC for 24VDC mode (62.8VDC for 48VDC mode )
|
|
Maximum charge current
|
80A
|
60A
|
100A
|
70A
|
80A
|
100A
|
120A
|
140A
|
|
BTS
|
Continuous output power
|
Yes Variances in charging voltage & S.D. voltage base on the battery temperature
|
|
BYPASS
&
PROTECTION
|
Input voltage waveform
|
Sine wave (grid or generator)
|
|
Nominal input frequency
|
50Hz or 60Hz
|
|
Overload protection (SMPS Load)
|
Circuit breaker
|
|
Output short circuit protection
|
Circuit breaker
|
| Bypass breaker rating |
40A
|
63A
|
63A
|
63A
|
|
Max bypass current
|
40Amp
|
80Amp
|
|
SOLAR
CHARGER
|
Maximum PV charge current
|
80A
|
100A(200A optional)
|
|
DC voltage
|
24V \ 48V Auto work
|
48V
|
|
Maximim PV array power
|
2000W
|
4000W
|
2000W
|
4000W
|
4000W
|
5000W(10000W for 200A optional)
|
|
MPPT range @ operating voltage(VDC)
|
32-145VDC for 24V mode,64-145V for 48V mode
|
64~145VDC
|
|
Maximum PV array open circuit voltage
|
145VDC
|
|
Maximum effciency
|
>98%
|
|
Standby power consumption
|
<2W
|
|
MECHANICAL
SPECIFICATIONS
|
Mounting
|
Wall mount
|
|
Dimensions (W*H*D)
|
620*385*215mm
|
670*410*215mm
|
|
Net weight (solar CHG) (kg)
|
36
|
41
|
41
|
69+2.5
|
75.75+2.5
|
75.75+2.5
|
|
Shipping dimensions (W*H*D)
|
755*515*455mm
|
884*618*443mm
|
|
Shipping weight (Solar CHG) (kg)
|
56
|
61
|
64
|
82.5+2.5
|
89+2.5
|
92+2.5
|
|
OTHER
|
Operation temperature range
|
0°C to 40°C
|
|
Storage temperature
|
-15°C to 60°C |
|
Audible noise
|
60dB MAX |
|
Display
|
LED+LCD
|
|
Loading (20GP/40GP/40HQ)
|
140pcs \ 280pcs \ 320pcs |
