Neexgent High Capacity Lifepo4 12.8v 200ah Battery Pack Lithium Battery For Solar Power System

• 6000 cycles @80% DoD, effectively reducing total cost of ownership;

• Low maintenance battery, good chemical stability;

• Additional battery management system (BMS) to prevent abuse;

• Due to its very low self-discharge (LSD) rate and no vulcanization risk, up to 6 months;

• Reduces downtime, saves time and increases productivity due to superior charge/discharge efficiency;

• Suitable for a wider range of applications with exceptionally high ambient temperatures: up to +60°C;

• The lithium battery delivers more Wh/Kg weight while also achieving 1/3 OF the SLA equivalent.

• Lithium iron phosphate can be used in most applications using lead acid, gel or AGM type batteries.

Product Overview

• LiFePO4 battery has a stable and high output voltage platform, which can effectively guarantee its output power.

• LiFePO4 battery has higher thermal stability and chemical stability, which can better guarantee its safety.

• LiFePO4 battery has a long life and low overall cost of maintenance and use.



Product Features

High cycle life

6000 cycles @80% DoD, effectively reducing total cost of ownership



Longer service life

Low maintenance battery, good chemical stability.



Built-in circuit protection

The battery management system (BMS) is designed to prevent abuse.



Better storage

Due to its extremely low self-discharge (LSD) rate and no risk of vulcanization, up to 6 months.



Quick charge

Reduces downtime, saves time and improves productivity due to superior charge/discharge efficiency.



Extreme heat resistance

Suitable for a wider range of applications where temperatures are unusually high: up to +60°C.



Lightweight

Lithium batteries provide more Wh/Kg weight while also achieving 1/3 of the SLA equivalent.



Matters needing attention

• Do not short-circuit, reverse polarity, crush or disassemble.

• Do not heat or burn.

• Do not soak in any liquid.

• Stored in 30~50% SOC. It is recommended to recharge every 3 months. Storage areas should be clean, cool, dry and ventilated



lifepo4 lithium battery pack lithium iron phosphate battery packlifepo4 12.8 volt battery pack lifepo4 battery pack 12.8vlifepo4 battery pack chargerlifepo4 battery packs12.8v 200ah lifepo4 battery pack12.8v lifepo4 battery packlifepo4 battery pack with bmslifepo4 12.8v battery pack

Tags:



Model NO.

NG04S200A

Nominal Capacity(AH)

200AH

Nominal Voltage(V)

12.8V

Standard Charge Current(A)

0.5C

Maximum Charge Current(A)

1C

Impedance(Ω)

0.2mΩ

Max. Discharge Current(A)

2C

Max.Charge Voltage(V)

3.65V

Discharge Cut-off Voltage(V)

2.5V

Charge Working Temp.(ºC)

0~55ºC

Discharge Working Temp.(ºC)

-30~75ºC

Cycle Life

6000 Cycles

Size 340x190x250mm
