Type |
Lead Acid Battery Pack |
Voltage | 12V |
Power | 150Ah |
Certificate |
UN38.3, UL, SGS, CE, PB |
Lead Time |
10 Days |
Payment |
T/T, L/C,Western Union |
Warranty |
5 Years |
SEALED VALVE-REGULATED LEAD ACID BATTERY: 12V 150AH
The NGX-12 General Purpose sealed lead acid battery stands out in standby applications (float charge),
delivering exceptional performance. Precision-crafted to meet the highest quality standards, the GP series
ensures both reliability and an extended lifespan. While suitable for intermittent cyclic use, we recommend
considering the NGX-12 Cyclic or NGX-12 Gel Cyclic series for more frequent and intensive cyclic usage.
Product Features:
Product Applications:
If you need any help with series, parallel or series-parallel battery configurations, please contact us!
Tags:
1. Specifications
Nominal Voltage |
12V |
|
Rated capacity (10 hour rate) |
150Ah |
|
Dimensions |
Length |
485±2mm(19.09inch) |
Width |
172±2mm(6.77inch) |
|
Height |
240±2mm(9.45inch) |
|
Total Height |
240±2mm(9.45inch) |
|
Approx. Weight |
44.5kg(98.1lbs)±3% |
2. Characteristics
Capacity (25℃) |
10HR(10.8V) |
150Ah |
|
3HR(10.8V) |
112.5Ah |
||
1HR(10.5V) |
83Ah |
||
Terminal type |
T16 |
||
Internal resistance (Fully charged,25℃) |
Approx.3.8m Ω |
||
Capacity affected by temperature (10HR) |
40℃ |
102% |
|
25℃ |
100% |
||
0℃ |
85% |
||
-15℃ |
65% |
||
Self-discharge (25℃) |
3 months |
Remaining Capacity:91% |
|
6 months |
Remaining Capacity:82% |
||
12 months |
Remaining Capacity:65% |
||
Nominal operating temperature |
25℃±3℃(77℉±5℉) |
||
Operating temperature range |
Discharge |
-15℃~50℃(5℉~122℉) |
|
Charge |
-10℃~50℃(14℉~122℉) |
||
Storage |
-20℃~50℃(-4℉~122℉) |
||
Float charging voltage(25℃) |
13.50 to 13.80V Temperature compensation: -18mV/℃ |
||
Cyclic charging voltage(25℃) |
14.40 to 14.70V Temperature compensation: -30mV/℃ |
||
Maximum charging current |
30A |
||
Maximum discharge current |
1200A(5 sec.) |
||
Designed floating life(20℃) |
10years |
3. Outer dimensions (mm)
4. Terminal Type (mm)
5. Construction
Component |
Positive plate |
Negative plate |
Container |
Cover |
Separator |
Electrolyte |
Safety valve |
Terminal |
Raw material |
Lead dioxide |
Lead |
ABS |
ABS |
AGM |
Gel |
Rubber |
Copper |
6. Constant Current Discharge Characteristics Unit:A(25℃,77℉)
F.V/Time |
10min |
15min |
30min |
60min |
2h |
3h |
4h |
5h |
8h |
10h |
20h |
9.60V |
293 |
240 |
146 |
90.0 |
54.8 |
39.0 |
30.6 |
26.0 |
18.4 |
15.3 |
8.09 |
9.90V |
284 |
234 |
143 |
88.7 |
54.5 |
38.8 |
30.4 |
25.9 |
18.3 |
15.2 |
8.08 |
10.2V |
272 |
226 |
138 |
86.4 |
54.0 |
38.5 |
30.2 |
25.7 |
18.1 |
15.2 |
8.05 |
10.5V |
260 |
218 |
135 |
83.7 |
53.2 |
38.3 |
30.0 |
25.5 |
18.0 |
15.1 |
8.01 |
10.8V |
246 |
206 |
130 |
81.0 |
51.8 |
37.5 |
29.1 |
24.7 |
17.5 |
15.0 |
7.95 |
7. Constant Power Discharge Characteristics Unit:A(25℃,77℉)
F.V/Time |
10min |
15min |
30min |
60min |
2h |
3h |
4h |
5h |
8h |
10h |
20h |
9.60V |
3159 |
2635 |
1633 |
1026 |
635 |
459 |
360 |
307 |
218 |
182 |
97.1 |
9.90V |
3064 |
2572 |
1600 |
1011 |
631 |
456 |
358 |
306 |
217 |
182 |
96.9 |
10.2V |
2938 |
2477 |
1551 |
985 |
625 |
453 |
355 |
304 |
215 |
181 |
96.6 |
10.5V |
2812 |
2393 |
1513 |
954 |
616 |
450 |
353 |
301 |
214 |
180 |
96.1 |
10.8V |
2654 |
2266 |
1458 |
923 |
600 |
441 |
342 |
292 |
207 |
179 |
95.4 |
Note: The above characteristics data can be obtained within three charge or discharge cycles.
8. 12v 150ah lead-acid battery charging and discharging diagram
