Neexgent High Quality 9bb Solar Panels 450w Half-cell Panels Solar 450w Mono Solar Panels

Neexgent 132 Cell 6bb/9bb Mono Solar Panel 500w Solar Panels Manufacturers Price From China

Type	Off grid solar inverter
Max.Power	5KW
Output Voltage	EU And US Standard
Certificate	PSE, FCC, CE, UN38.3, Msds, UL, SAA And ROHS
Lead Time	10 Days
Payment	T/T, L/C,Western Union
Warranty	25 Years

Suitable for use in USA/Puerto Rico,and Canada where split phase power standard is used.

Product Features:

solar inverter store best inverter for solar panels solar charge controller inverter solar inverter outdoor hybrid inverters solar

Tags:

Technical Specifications:

MODEL	NG 5032US
Continuous Output	5000VA/5000W
System DC Volt	48VDC
AC Input Voltage	110/120VAC (Phase-Neutral)
Maximum Parallel	Up to 3 units
PV INPUT/SOLAR CHARGING
Max PV Input Power	8000W(4000W each input)
Max PV input Volt	145V(open circuit Voc)
MPPT Range	60-110VDC
Number of PV Input	2
Max Charging Current	160A (80Ax2)
OUTPUT MODE
Output Waveform	Pure Sine Wave
AC Output Mode	120V L-N/240V L1-L2 /208V L1-L2 3-Phase
Frequency	50 / 60 Hz,auto-sensing
Max Bypass Current	40A
Max Efficiency	>90%
Max Utility Charging	60A
Max Utility + Solar Charging	220A
Max Bulk/Float Charge	58.4V
ENVIRONMENTAL/MECHANICAL SPECIFICATIONS
Communication Port	USB / RS232/Dry Contact
Operating Temp	o-5or
Dimension,D x Wx H(mm)	623610130mm
Net Weight	30KG
