LiFePO4 batteries exhibit superior environmental adaptability, functioning effectively across a broad temperature range, and can undergo thousands of cycles without a drop in performance. As a result, they find extensive application in electric vehicles, energy storage setups, solar panels, and various power systems that necessitate efficient, dependable, and eco-friendly power sources.
Advantages of LiFePO4 batteries:
Environmentally Friendly: Green, non-toxic, and uses widely available, cost-effective raw materials.
Long Lifespan: Offers high capacity, durability, and excellent shock resistance, with up to 6000 cycles at 80% Depth of Discharge (DOD).
Low Self-Discharge: Maintains good performance even in low-temperature environments.
Efficient Charging: Demonstrates robust charging acceptance and fast-charging capabilities.
Over-Discharge Protection: Exhibits strong resistance to over-discharge and retains charge well.
Maintenance-Free: Requires no acid or water for upkeep during usage.
Powerful Discharge: Excels in high-current discharge, particularly advantageous for startup and climbing.
Compact and Lightweight: Offers a smaller size and reduced weight compared to other battery types.
Environmentally Safe: Contains no heavy metals and is eco-friendly.
Enhanced Safety Features: Equipped with an internal Battery Management System (BMS) for full protection, including high voltage safeguards, ensuring high reliability.
No Memory Effect: Does not suffer from memory effects, preserving long-term performance.
High-Temperature Resilience: Maintains good performance even in elevated temperature conditions.
Large Single Cell Capacity: Provides substantial capacity per individual battery cell.
Enhanced Safety: Possesses a high level of safety, with no risk of explosion or fire.
Low Self-Discharge Rate: Maintains a discharge rate of ≤3% per month, ensuring long-term storage viability.
Accessory specifications Busbars: 90*20*2mm or 100*20*2mm
(We offer two options for busbars; for additional details, please contact us.)
Screw Size: M6
1 Battery Kit: Includes 1 busbar, 2 nuts, and 2 screws
For 4 Battery Kits: You'll receive 4 busbars, 8 nuts, and 8 screws.
(If you require more, please reach out to us via our online support.)
Cautions:
Keep away from fire or high temperatures.
Ensure correct terminal connections when charging.
Prevent short circuits.
Handle with care to avoid shocks or vibrations.
Avoid disassembly or deformation.
Keep away from water.
Use batteries of the same make, type, and model together.
Store out of children's reach.
Charge using an appropriate charger only.
Never use a modified or damaged charger.
Avoid leaving the battery in the charger for over 24 hours.
Store in a cool, dry, well-ventilated area.
Upon receiving batteries from the factory, we will carefully repackage them in custom-designed foam and cartons. This is done because the original cartons are not optimal for international transport, as they are primarily suited for short-distance transportation.
Prior to shipment, a comprehensive battery testing process is carried out to guarantee top-notch quality.
Tags:
Model NO.
NG205
Nominal Capacity(AH)
205AH
Nominal Voltage(V)
3.2V
Standard Charge Current(A)
0.5C
Maximum Charge Current(A)
1C
Impedance(Ω)
0.2mΩ
Max. Discharge Current(A)
2C
Max.Charge Voltage(V)
3.65V
Discharge Cut-off Voltage(V)
2.5V
Charge Working Temp.(ºC)
0~55ºC
Discharge Working Temp.(ºC)
-20~55ºC
Cycle Life
6000 Cycles
Size
174*200*54mm
Household Solar Energy System: LiFePO4 battery cells provide exceptional safety, durability, and efficiency, making them a reliable and eco-friendly choice for home solar power. They enable energy independence, backup during outages, and cost savings for homeowners.
Portable Electronics: These batteries power a wide array of portable devices, including smartphones, laptops, tablets, and digital cameras. Their lightweight design is well-suited for these applications, offering high power in a compact package.
Business & Commercial: LiFePO4 batteries are commonly employed in business and commercial applications, including alarm systems, solar panel systems, and security lighting, ensuring dependable power supply.
Marine Applications: With their lightweight and high-power capabilities, LiFePO4 batteries are the preferred choice for propelling fishing boats and kayaks.
Industrial Settings: LiFePO4 batteries excel in industrial environments due to their ability to endure high temperatures and maintain charge over extended periods. They are the ideal choice for powering machinery and equipment in such settings.
