Neexgent 1.6kw-10kw Hybrid Solar Inverter with MPPT for Solar Energy Systems Off Grid Solar Panel Power System

Type

NEX Model Hybrid Inverter

Max.Power

1.6-10KW

Output Voltage

EU And US Standard

Certificate

EN-IEC 60335-1, EN-IEC 60335-2-29, IEC 62109-1

Lead Time

10 Days

Payment

T/T, L/C,Western Union

Warranty

5 Years

◉ Small no-load loss, under half of comparable high-frequency machines
◉ Pure sine wave output, adaptable to various loads
◉ Output short-circuit protection
◉ User-adjustable parameters
◉ Optional solar controller (PWM/MPPT)
◉ Optional BMS communication
◉ Optional RS485 communication
◉ Optional WIFI (requires Bar DataLogger)

Hybrid solar inverter installation

NEX Model 1.6~10Kw 24V/48V Hybrid Solar Inverter – Off-Grid Island

The NEX Model Hybrid Inverter efficiently stores surplus solar energy in a battery for personal use.

It functions similarly to a standard grid-tie inverter but offers multiple modes, including battery backup

for partial blackout support. NEX inverters are cost-effective and easier to install compared to complex

battery storage systems that often require multiple inverters.



Key Features of NEX Model:

  • Operates with AC input mains and panels, even without batteries
  • Adjustable charging current and voltage to meet user preferences
  • Multiple operating modes: Grid-tie, off-grid, and grid-tie with backup
  • Pure sine wave output
  • Minimal self-consumption
  • Programmable power allocation for PV, battery, or grid sources
  • Real-time monitoring and control via dedicated software
  • Expandable capacity through parallel operation, supporting up to 9 units



NEX Model Hybrid Inverter Operating Modes:

NEX Model Hybrid Inverters can operate in several modes:

  1. Grid-tie: Functions like a standard solar inverter without a battery.
  2. Hybrid: Stores excess solar energy for evening use, enhancing self-sufficiency.
  3. Backup: Acts as a solar inverter when the grid is available and switches to backup power during outages.
  4. Off-grid: Charges the battery with excess solar energy and powers loads without a grid connection.



While many hybrid inverters can function in these modes, only a few are suitable for off-grid systems and can

start and run a backup power source if necessary.

Hybrid solar inverter for off-gridSolar inverter hybrid systemHybrid solar inverter efficiencyHybrid solar inverter benefitsFor remote monitoring capabilities, the Bar DataLogger must be purchased separately to enable

Wi-Fi functionality. This allows you to conveniently check the system's status anytime and anywhere,

enhancing user-friendliness and accessibility.



Tags:



Capacity(VA) 1KVA12V 1.3KVA12V 1.5KVA12V 2KVA24V 3KVA24V 3.8KVA24V 5KVA48V 6.3KVA48V 8KVA48V 10KVA48V 12.5KVA48V
MODEL NEX1020MP NEX1312MP NEX1512MP NEX1624MP NEX2424MP NEX3024MP NEX4048MP NEX5048MP NEX6448MP NEX8048MP NEX10048MP
Input
Voltage(DC) 12V 24V/48V 48V
Nominal Voltage 220VAC(Standard) /110VAC (Custom)
Voltage Range 154-265VAC ;185-264VAC ( selectable)
Frequency 50-60HZ Auto sensing
Output
Walt 800W 1000W 1200W 1600W 2400W 3000W 4000W 5000W 6400W 8000W 10KW
Voltage 220VAC±10% (110VAC±10%)
Frequency 50/60HZ
Waveform Pure Sine Wave
Transfer Time (AC to DC) <8ms
Transfer Time (DC to AC) <8ms
Output Voltage Regulation 土10%
Bypass Mode Yes
Saver Mode Yes
Efficiency >98%
Protection
Input Protection Circuit Breaker
Output Protection Circuit Breaker
Battery
Battery Type AGM-Deep Cycle,GEL,LIFEP04
UP to 500Ah
Charging Current 20A 25a 30A 15A 30A 35A 20A 29A 39A 50A 60A
Low Level disconnect (Selectable) 10V or 10.5V 24V:20V or 21V
48V:40V  or 42V
LCD indicator status Input AC,Output AC
Battery DC,Output Load
Alarm,Fault
Battery Charge Level
Output Frequency
LED indicator status AC Line In:Green
Inverter:Green
Charging :Yellow
Alarm :Red
Battery low alarm 12V:battery light discharge11.5V;battery load discharge 11.5V@load<20%;
11V@load>50%/10.5V@load>50%;
24V:battery light discharge23V;battery load discharge 23V@load<20%;
22V@load>50%/21V@load>50%;
48V:battery light discharge46V;battery load discharge 46V@load<20%;
44V@load>50%/42V@load>50%;
Battery low recovery 12V:battery light discharge12V;battery load discharge 12V@load<20%;
11.5V@load>50%/11V@load>50%;
24V:battery light discharge24V;battery load discharge 24V@load<20%;
23V@load>50%/22V@load>50%;
48V:battery light discharge48V;battery load discharge 48V@load<20%;
46V@load>50%/44V@load>50%;
DC low voltage shutdown 12V:battery light discharge11V;battery load discharge 11V@load<20%;
10.5V@load>50%/10V@load>50%;
24V:battery light discharge22V;battery load discharge 22V@load<20%;
21V@load>50%/20V@load>50%;
48V:battery light discharge44V;battery load discharge 44V@load<20%;
42V@load>50%/40V@load>50%;
DC high voltage alarm and fault 16V 32V 64V
DC high voltage recovery 15V 30V 60V
Maximum PV array power 800W 1600W 3200W
MPPT/PWM input voltage range MPPT:15-150VDC
PWM:15-50VDC
MPPT:30-150VDC
PWM:30-105VDC
MPPT:60-150VDC
PWM:60-105VDC
Maximum PV array open circuit voltage MPPT:150VDC
PWM:50VDC
MPPT:150VDC
PWM:105VDC
MPPT:150VDC
PWM:105VDC
Maximum solar charging current 60A 120A
Alarm
Low battery alarm Audible alarm-1 beeping per second
Overload alarm Audible alarm-continuous beeping
Fault Audible alarm-continuous beeping
Environment
Temperature -10~50℃
Humidity C0-95%,Non condensing
Accoustic Noise(db) <45db
