Neexgent EVE 18650 15P 1500mah 3.6V ICR Battery

The cylindrical cell of the lithium-ion battery cell EVE Energy ICR18650-15P is a high-precision, physical battery model with global validity.



Type

18650 ICR Lithium Battery Cell

Max.Power

3.6V 1500mah

Brand

EVE

Certificate

CB, UN38.3, BIS, UL, PSE, RoHS

Lead Time

10 Days

Payment

T/T, L/C,Western Union

Warranty

25 Years

EVE 18650 cells stand as a dependable, premium choice for fueling your device. With EVE's patented Long Life Technology, these batteries boast the market's finest capacity ratings, ensuring enduring power and performance. Count on EVE 18650 cells for sustained effectiveness without overheating or reduced lifespan due to memory impact. Furthermore, enjoy extended storage life and remarkable cycle life properties. For all your battery requirements, place your trust in EVE.



These EVE 15P 18650 batteries are classified as grade A cells, distinctly original and not rebadged. They outperform the LG MJ1 and rival the widely acclaimed Sanyo NCR18650GA. These attributes make them exceptionally fitting for assembling battery packs due to their unwavering State of Charge (SoC) voltage, internal resistance, capacity, and performance consistency.



  • High-energy density
    Up to 185 Wh/kg



  • High rate discharge
    Capable of maximum 50A continuous discharge, and 100A at pulse discharge



  • Fast charging
    Up to 8A charging



  • Long cycle life at room temperature
    Meet the requirements of long operating life



  • Excellent high temperature and low temperature cycle
    between 0-55℃



  • High-safety
    Pass CB, UL1642, UN38.3



To achieve optimal balanced charging, speed, and safety, it is advisable to employ an external charger. (Usage Recommendations)



The batteries will be initially test-charged. It is imperative to fully charge them to attain maximum capacity. Neglecting this step could result in potential long-term cell complications.



This specific cell is devoid of protection and is designed for utilization within safeguarded battery packs. To ensure secure operation, it necessitates supplementary protection in the form of a protection circuit board or a Battery Management System.



li ion 18650 battery 1500mah 3.6 vicr18650 battery 1500mah18650 battery 1500mah 3.6 v li ion1500mah 18650 batteryli ion battery 1500mah18650 battery 1500mah 3.6 v18650 battery 1500mah 3.6 v li ionlithium battery 3.7 v 1500mah

Tags:



18650 li ion battery 3.6 v

Model No.

EVE-ICR18650/15P

Typical Discharge Capacity

1500mAh
Charge: 0.75 (0.5C), 4.20V, CCCV 100mA cut-off
Discharge: 1.5A (0.2C), 1.50V DC cut-off

Minimum Discharge Capacity

1480mAh
Charge: 0.75A, 4.20V, CCCV 56mA cut-off
Discharge: 0.56A, 2.50V DC cut-off

Typical Voltage

3.60V

Standard Charge

CCCV, 0.1A, 4.20± 0.05V, 50mA cut-off

Rapid Charge

CCCV, 1.25A, 4.20± 0.05V, 50mA cut-off

Standard Discharge

DC, 0.5A, 2.50V cut-off

Max. Continuous Discharge

DC, 7.5A, 2.50V cut-off

Charge/Discharge Voltage Range

4.20~2.50V

Cell Weight

36.0g Max
Cell Dimensions

Height: 65.00±0.15mm
Diameter: 18.35±0.10mm

Operation Temperature
(Cell Surface Temperature)

Discharge: -20 to 60°C (Pack cut-off temperature 70°C)

Charge: 0 to 15 °C

≤0.5A

Charge: 15 to 50 °C

≤1.25A

Storage Temperature
(At Shipping SOC)

1 year

0~25°C

3 months

0~45°C

1 month

0~60°C



eve 18650

NO.

Part Name

Material

Q’Ty

1

Cell

Cylindrical

200 pcs/box

2

Packing Guide

Manila

36 pcs/box

3

Box(Packing Case In)

SW

2 pcs/box

4

Silicagel

Si

2 pcs/box

5

Bag PE

PE

1 pcs/box

6

Box(Packing Case Out)

SW/DW

1 pcs/box

7

Tape

PE

0.01 rol/box

8

Product Label

Art Paper

1 pcs/box
